Portable Fire Pump Diesel Engine

Diesel engine fire pump XBC-D equipment is powered by X6135, 12V135, 4102, 4105, 6102 and other series diesel engines. The diesel engine (can be equipped with a clutch) is connected with the fire pump through a highly elastic coupling to form a fire pump group. The unit also includes a diesel tank. , cooling water tank, fan, control panel (for automatic units) and other components.

The diesel engine fire pump set adopts ISW pump.
1. The pump is the horizontal structure, the inlet and outlet are the same in diameter, and lying in the same center line, which can be installed in the pipeline as valve, the floor space needed is small, if the protection cover is added, it can be put in the open air;
2. The impeller is installed on the major axis of the motor directly, the axial is short in size, the structure is compact, can calibrate radial and axial load that produced by pump rounding effectively, thus guaranteed the pump operating steadily, vibration, and low noise;
3. The axle seal adopts machinery seal or machinery seal sets, uses imported titanium alloy sealed ring, medium-sized high-temperature resistance machinery seal and adopts the hard alloy material, wear-resisting seal, which can lengthen the life of machinery seal effectively;
4. It is convenient to install and overhaul, no need to dismantle or move pipeline system; just lifting off pump conjunction flat nut can take all rotor parts out;
5. Can choose series or parallel operation according to your requirements for flow and lift;
6. Can be installed horizontally according to the pipeline system requirement.

An FDC is an external connection point that allows the fire department to supplement the water supply to the fire protection system using their hoses and equipment if needed.

Diesel engine fire pump set is a new type of fire-fighting equipment developed by our company in strict accordance with the national standard GB6245-2006 “Fire Pump Performance Requirements and Test Methods” and the American Fire Protection Association standard NEPA20 “Installation of Centrifugal Fire Pumps” and other standards (hereinafter referred to as equipment ), this series of equipment can be divided into three sub-series, XBC-IS, XBC-S, XBC-D, etc. The equipment has a wide range of pressure and flow, and its application can almost meet various occasions required by fire protection.

The diesel engine equipped with the equipment is made of domestic or imported high-quality products. It has the characteristics of good starting characteristics, strong overload capacity, compact structure, convenient maintenance, simple use, and high degree of automation. It is an advanced and reliable fire-fighting equipment.

Diesel engine fire pumps are often used for emergency water supply in high-rise buildings, water companies, steel plants, wineries, chemical plants, hotels, hospitals, and other large-scale projects. Diesel engine fire pump is suitable for unattended emergency water supply system. The product has the characteristics of advanced technology, high degree of automation, superior performance, complete protection functions, reasonable structure, simple installation, and high cost performance. net pressure. Diesel engine fire pumps are selected according to different working conditions: single-stage single-suction centrifugal pumps, high-pressure multi-stage pumps, double-suction split pumps, etc.

1. Natural ventilation When setting up and arranging diesel machine fire pumps, it’s first necessary to consider adequately sized ventilation openings and exhaust openings, and secondly, to insure that there’s enough fresh air to supply diesel machine combustion within the temperature limit. In this way, the heat of the circulating cooling water can be taken down by the water force radiator to take down the heat radiated from the face of the unit.

2. Forced ventilation when the natural ventilation conditions can not be met, forced ventilation can be espoused. Inlet suckers and exhaust suckers can be installed at the reflections. The addict specifications and the position of the air bay and outlet in the machine room should be named to give enough cold air for the diesel machine. At the same time, the hot air in the pump room is taken down, and the small air input volume of the unit needs to be about 6- 7 times that of the diesel machine air input.

3. Arrange grooves and seamsters By arranging seamsters around the unit foundation and arranging mountain grooves in the middle of the unit foundation, the purpose of this is to grease the flushing of sewage and diesel oil painting, thereby icing the sanitation of the pump room.

Flow：80-4000 GPM
Head：3-15 Bar
Power：11-1000 kw
The Diesel Single-stage Single-suction Fire Pump is a versatile solution suitable for a wide range of applications. From hotels, hospitals, and sports arenas to chemical plants, refineries, metallurgical facilities, energy plants, and pharmaceutical companies, this pump set ensures reliable fire protection. It is also ideal for shopping malls, commercial complexes, office buildings, and high-end residential towers. Whatever the setting, the Diesel Single-stage Single-suction Fire Pump delivers dependable performance to safeguard lives and properties from fire risks.

Fire pumps are divided into different types according to different classification methods. Due to their fully sealed, leak-free and corrosion-resistant features, they are widely used in environmental protection, water treatment, fire-fighting and other departments to pump various types of liquids. The ideal pumps for polluting civilized workshops and civilized factories are similar to the pumps for fire protection systems, but the head and flow are different.

Diesel engine self-priming pump can absorb and discharge liquid containing large particles of solid and long fiber impurities, the pump group has the characteristics of simple structure, good self-priming performance, strong sewage capacity, high efficiency and energy saving, easy to use and maintenance.

The diesel engine pump is a water pump powered by a diesel engine, which completely reduces the labor intensity of workers, and is easy to use, move, and install, with little maintenance and stable performance.

The image shows the XBC-IS 6-25 diesel engine fire pump, which is suitable for various small and medium-sized firefighting scenarios.
The XBC-IS Diesel Engine Fire Pump is the ultimate solution for reliable fire protection in a wide range of settings, including factories, commercial buildings, residential areas, public facilities, and even agricultural fields. Designed to meet emergency firefighting needs, this pump ensures a dependable water source and increased water pressure, regardless of the availability of electricity.

The XBC-ISO Diesel Engine Fire Pump Set is an efficient and reliable firefighting equipment that combines the power of a robust diesel engine with the advantages of an ISO single-stage centrifugal pump. This pump set is ISO certified, ensuring excellent quality and performance. The XBC-ISO pump set is suitable for emergency firefighting scenarios, particularly ideal for high-rise water supply, building firefighting, central air conditioning water circulation, industrial process system circulation, cooling systems, boiler water supply, industrial water supply and drainage, water plant supply, irrigation in plantations, and more. This firefighting pump set is equipped for emergency rescues and can operate efficiently even during power outages. Moreover, its end-suction design simplifies operation and saves installation time.

Diesel engine fire pump has high efficiency, long operating life and high reliability. It can be used in independent fire water supply system, some can be used in fire protection and domestic common water supply system, and it can also be used in construction, municipal, industrial and mining, water supply and drainage, ships, field operations, etc.

The diesel engine-driven fire pump unit is a high-performance emergency solution specifically designed for industrial and municipal projects. One of its key advantages is its ability to deliver strong and continuous water pressure even during power outages or unstable grid conditions, ensuring the fire protection system operates reliably in critical situations.

Powered by a premium diesel engine and equipped with an automatic control panel, the unit offers features such as one-touch startup, auto-switching, and smart monitoring. Its compact structure and easy installation make it ideal for essential applications such as petrochemical plants, power stations, logistics centers, and water facilities—providing independent, powerful, and reliable fire protection.

Manufactured in compliance with international standards and thoroughly tested, this pump unit ensures stable performance, low maintenance, and excellent resistance to high temperature and corrosion, making it the perfect choice for demanding industrial and municipal environments.

The XBC-IS Diesel Fire Pump Set (with Cummins diesel ) is a versatile solution suitable for a wide range of applications. From hotels, hospitals, and sports arenas to chemical plants, refineries, metallurgical facilities, energy plants, and pharmaceutical companies, this pump set ensures reliable fire protection. It is also ideal for shopping malls, commercial complexes, office buildings, and high-end residential towers. Whatever the setting, the XBC-IS Diesel Fire Pump Set delivers dependable performance to safeguard lives and properties from fire risks.

The XBC-ISO pump set is suitable for emergency firefighting scenarios, particularly ideal for high-rise water supply, building firefighting, central air conditioning water circulation, industrial process system circulation, cooling systems, boiler water supply, industrial water supply and drainage, water plant supply, irrigation in plantations, and more. This firefighting pump set is equipped for emergency rescues and can operate efficiently even during power outages. Moreover, its end-suction design simplifies operation and saves installation time.

The diesel engine fire pump has the characteristics of good starting characteristics, strong overload capacity, compact and reasonable structure, convenient maintenance, simple and reliable use, etc. The unit is equipped with protection functions such as overspeed, low oil pressure, three start failures, high water temperature, low oil level, and low battery voltage. Diesel engine fire pump is composed of diesel engine, chassis, cooling water tank and fan, high elastic coupling, water pump, diesel tank and control panel and other equipment. The diesel engine fire pump is directly connected with the diesel engine through a highly elastic coupling or a diaphragm coupling, and is installed on a common channel steel chassis.

This diesel fire pump adopts OTS pump, which has large flow and fast speed. The diesel engine fire pump has automatic, manual and fault self-checking functions. It can monitor the working status of the whole process, restore the function of failure start, automatic pre-lubrication and automatic restart of preheating, so that the equipment start-up is safer and more reliable.

Single-cylinder diesel self-priming fire pump has the characteristics of high head, light weight, simple structure, high efficiency, convenient installation and maintenance, flexible movement, etc., for agricultural drainage and irrigation, construction, domestic water pumping. It is especially suitable for agricultural irrigation in mountainous and hilly areas.

The diesel engine fire pump has the characteristics of good starting characteristics, strong overload capacity, compact and reasonable structure, convenient maintenance, simple and reliable use, etc. The unit is equipped with protection functions such as overspeed, low oil pressure, three start failures, high water temperature, low oil level, and low battery voltage. Diesel engine fire pump is composed of diesel engine, chassis, cooling water tank and fan, high elastic coupling, water pump, diesel tank and control panel and other equipment. The diesel engine fire pump is directly connected with the diesel engine through a highly elastic coupling or a diaphragm coupling, and is installed on a common channel steel chassis.

This is 3000gpm, 10bar XBC-S diesel engine fire pump, customer requires third-party company inspection, inspection qualified shipment. The technicians are inspecting the products in strict accordance with the inspection standards. Our products will be strictly tested before leaving the factory to ensure product quality.

In today’s industrial and large-scale building fire protection systems, a reliable fire pump is the cornerstone of safety. The industrial-grade diesel-driven horizontal split case fire pump system is engineered to meet the demands of high-intensity and high-standard scenarios. With a compact split-case design powered by a high-performance diesel engine, it ensures fast startup and stable operation under critical conditions.

Its robust and durable pump body is built to withstand high-pressure operation for extended periods, making it ideal for emergency fire suppression. The double suction impeller significantly improves hydraulic efficiency and delivers a steady high-volume water supply. The diesel drive eliminates concerns over unstable power supply or outages, making this unit a dependable solution in petrochemical plants, power stations, and large logistics hubs.

Equipped with an intelligent control panel, the system supports automatic start/stop, fault alerts, and remote monitoring, ensuring enhanced operational safety. Pre-assembled and tested before delivery, the unit is easy to install and maintain—an essential component in any modern fire protection strategy.

Maintaining a diesel engine fire pump is crucial to ensure its reliable operation in case of emergencies. Below are some essential maintenance tips for a diesel engine fire pump:

Regular Inspections: Schedule periodic inspections by a certified technician to assess the condition of the fire pump. Inspect the engine, fuel system, cooling system, electrical connections, and other critical components.
Battery and Electrical System: Inspect and maintain the battery and electrical connections to ensure reliable engine starting. Clean any corrosion from terminals and replace weak batteries promptly.

Run Regular Tests: Perform routine tests of the diesel engine fire pump to verify its functionality. Regular testing will help identify potential issues and ensure the pump is ready for operation during emergencies.

Follow Manufacturer’s Guidelines: Always adhere to the maintenance guidelines provided by the fire pump manufacturer. These guidelines are tailored to the specific model and will help extend the life of the equipment.

Train Personnel: Ensure that the personnel responsible for maintaining and operating the diesel engine fire pump are well-trained and knowledgeable about its components and maintenance requirements.

Emergency Plan: Have a contingency plan in place in case the fire pump fails during an emergency. This plan should include alternative water sources or backup fire suppression systems.

Remember, regular maintenance is essential to keep the diesel engine fire pump in optimal working condition and ready to protect lives and property during critical situations. Always prioritize safety and follow best practices when handling and maintaining fire protection equipment.

Diesel engine fire pump, as a fixed fire extinguishing equipment, has been widely used in fire diversion, especially in emergencies such as no power supply or abnormal power supply, it can also be equipped with other diesel engines as power engines according to the needs of users.

Flow：80-2700 GPM
Head：10-24 Bar 145-350 psi
Power：11-1000 kw
Caliber：65-300 mm
Frequency：50 or 60 Hz
Working Pressure：≤2.5 MPa

All places need to be equipped with fire-fighting facilities, and fire pumps are the water intake equipment for fire-fighting facilities. At least one or two fire pumps are equipped. Our commonly used fire pumps are electric fire pumps and diesel engine fire pumps. The difference between them is that electric fire pumps require power systems. supply. In case of power failure, the diesel engine fire pump can be started at any time to make up for the original position of the electric fire pump.

The diesel engine fire pump is installed together with the electrical instrument, with complete functions, compact structure, automatic fault alarm, accepting the starting signal, and can automatically complete the starting procedure and run at full load quickly. When the diesel engine fire pump is insufficient in fuel, low battery voltage, and high lubricating oil temperature , enough to ensure that the diesel engine fire pump starts in a low temperature environment, the entire system of the diesel engine fire pump is safe, reliable, and easy to use. Diesel engine fire pumps can be widely used in environmental protection, water treatment and fire protection departments to transport various liquids by using their own advantages.

Diesel engine fire pumps are relatively common in life, and their performance requirements are relatively high. In ordinary use, more attention should be paid to maintenance, so as to prolong the service life of the pump. Because diesel fire pumps are not omnipotent, there will be some problems in daily use, so when choosing equipment, we must pay attention to whether the quality of the equipment meets the national standards. As fire equipment, all kinds of equipment must be To ensure performance, avoid affecting use in disaster situations and delaying rescue.

Diesel engine fire pump, as a fixed fire extinguishing equipment, has been widely used in fire diversion, especially in the case of no power supply or abnormal power supply and other emergencies, other diesel engines can also be equipped as power engines according to the needs of users.

The XBC-JC Diesel Engine Driven Vertical Turbine Fire Pump is a reliable and efficient hydraulic solution designed for extracting water from deep wells and hot springs. With its unique long shaft design and advanced technology, this pump delivers powerful pumping capacity and lift height, swiftly transporting large volumes of water to desired locations. Its compact structure makes it suitable for various complex working environments, including construction sites and agricultural irrigation. Equipped with an automatic start-stop function, the XBC-JC pump intelligently controls its operation, saving energy and reducing maintenance costs. It finds versatile applications in firefighting, urban water supply systems, and hot spring facilities, providing dependable hydraulic support for smooth operations.
