Industrial Diesel Fire Pump Equipment – Integrated Pump and Control System for Fire Water Supply Requirements

The dual-pump diesel fire pump system achieves uninterrupted water supply through a primary and backup redundancy design, featuring high reliability and large flow output, and is suitable for large-scale industrial and building fire protection projects.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar (40-300 psi)
3.Power：Diesel & Electric Pump:1.5-710kw Jockey Pump:0.55-160kw
4.Speed：740-2900 r/min
The EDJ Fire Pump Set includes diesel engine pumps, electric pumps and jockey pumps.
In various fields, our products find applications in large hotels, hospitals, schools, office buildings, supermarkets, commercial residences, subway stations, train stations, airports, various transportation tunnels, petrochemical plants, thermal power plants,oil storage tanks, large warehouses, industrial and mining enterprises, seawater injection, etc.

There are several types of fire pumps, each designed for specific applications. Two common categories are centrifugal and positive displacement pumps.

Centrifugal pumps are widely used in fire protection systems due to their simplicity and reliability. They work by imparting kinetic energy to the water, which then exits the pump under pressure. These pumps are well-suited for maintaining consistent water pressure for fire suppression.

Positive displacement pumps, on the other hand, use a different mechanism. They trap water in a chamber and then force it into the discharge piping, creating pressure. Positive displacement pumps are typically used in situations where high pressure or low flow is required.

The choice of pump depends on the specific needs of the fire protection system and the facility it serves.

ZJBetter provide three types of fire pump system, such as diesel engine fire pump set, electric driven fire pump set, EDJ fire pump set.

Standardized open-frame diesel fire pump units have the advantages of open structure, convenient installation, simple maintenance and independent power, and are suitable for industrial and building fire protection systems to ensure stable water supply in emergency situations.

A fire pump starts when the pressure in the fire protection system drops below a set threshold, indicating water flow caused by sprinkler activation or manual use of a fire hose. The pressure drop is detected by pressure-sensing devices, triggering the fire pump to activate and provide adequate water pressure.

Double power fire pump is mainly composed of electric fire pump, diesel fire pump and regulator pump, in no power supply or power supply (mains) is not normal will start the diesel fire pump, to ensure the fire water supply in these unexpected circumstances.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

The next-generation diesel-driven fire pump system combines smart control, efficient water delivery, and modular design. Ideal for high-risk fire protection scenarios, it complies with NFPA20 standards, supporting intelligent firefighting infrastructure.

The application of diesel engine fire pump is also more and more extensive. Diesel engine fire pump is a common necessary facility. Only when the fire signal comes, and the electric water pump fails or the power supply is cut off, the diesel engine fire pump will automatically start. The diesel engine fire pump is installed together with the electrical instrument, with complete functions, compact structure, automatic fault alarm, accepting the starting signal, and can automatically complete the starting procedure and run at full load quickly. , enough to ensure that the diesel engine fire pump starts in a low temperature environment, the entire system of the diesel engine fire pump is safe, reliable, and easy to use.

Pipeline fire pumps have become the core equipment of fire protection systems with their high hydraulic performance, stable water supply and energy-saving advantages. They are suitable for high-rise buildings, industrial plants and public facilities, ensuring sufficient water pressure and reliable operation during fire fighting.

EDJ series fire pump set consists of electric pump + diesel pump + jockey pump and all accessories.
The pressure switch and the control cabinet can automatically turn on/off the three pumps – the electric pump and the pipe charging pump work when there is electricity, and the diesel pump is started when the power is off.
Flow range: 50-5000 GPM
Pressure range: 4-14 bar
Power range: 4-325 KW

The standalone diesel fire pump system offers powerful power and exceptional reliability, automatically starting and maintaining continuous water supply even during power outages or harsh environments. Powered by a highly efficient diesel engine, this system features an intelligent control system and multiple safety features. Widely used in industrial plants, high-rise buildings, oil depots, and ports, it provides a stable, high-pressure water source for firefighting systems, ensuring uninterrupted emergency water supply. It’s an ideal firefighting solution for power outages.

Explore the future of fire safety with intelligent fire pump systems. Learn about their advantages, such as automated control, remote monitoring, energy efficiency, and seamless integration with other safety devices. Discover how these systems enhance emergency responses, reduce human error, and improve environmental performance. A must-read for anyone looking to upgrade fire protection with cutting-edge technology.

According to the needs of system operation control and maintenance management, the fire pump electrical control cabinet mainly has the functions of starting and stopping the pump, switching the main and standby pumps, manual automatic switching, dual power switching, inspection, protection, and feedback mechanical emergency start.

The high-efficiency electric fire pump system integrates a main electric pump, a jockey pump, a control cabinet, and a pressure tank; it supports various configurations regarding flow rate, head, and pump type, making it suitable for fixed fire water supply systems in buildings, warehouses, and industrial facilities.

EDJ fire pump set consists of main electric pump (motor driven), standby diesel pump (diesel engine driven) and jockey pump. The pump is assembled from discharge and suction pipes and a control panel. The fire pump system can be customized for different uses such as high-rise buildings, warehouses, facilities, hospitals, supermarkets, shopping malls, villas, apartments, etc.

The EEJ Fire Pump System is an innovative solution designed to enhance fire safety in various settings. With exceptional performance and efficiency, the EEJ Fire Pump System delivers high pressure and large flow capacity, enabling rapid and effective fire suppression. Its intelligent features, including real-time monitoring and remote control capabilities, contribute to the system’s reliability and ease of operation. Overall, the EEJ Fire Pump System is a reliable choice for safeguarding lives and properties, making it an ideal fire protection solution for commercial buildings, industrial facilities, and residential areas.

Fire pump controllers are devices that monitor and control the operation of fire pumps. They ensure that the pump starts automatically during an emergency, regulate pressure, and provide safety features. Controllers play a crucial role in the overall functionality of the fire pump system.

Flow: 30-9000 GPM
Head: 3-20Bar
Speed: 740-2900r/min
Material: HT200, SS304, Bronze

The EJ Fire Pump Set is combined an electric pump and a jockey pump.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

Fire pumps are often required to have backup power sources, such as diesel generators or uninterruptible power supplies (UPS), to ensure they function during power outages.

Compact modular fire pressure boosting station with stainless steel multistage pumps and intelligent control system. Designed for high-rise buildings, parking garages, and commercial facilities, it offers constant pressure supply, energy efficiency, easy installation, and 24/7 automated operation for stable and reliable fire protection.

The integrated diesel fire pump unit adopts an integrated design of diesel engine, high-efficiency fire centrifugal pump and intelligent control system. It has the advantages of automatic start, independent power, large flow, high head, continuous water supply, intelligent monitoring and multiple safety protections. It is widely used in large buildings, industrial plants, petrochemical plants, airports, ports, warehousing and logistics, municipal fire protection and public infrastructure, providing a stable and reliable emergency fire water supply solution for fixed fire protection systems.

Fire pumps are widely used in our production and life, such as in water treatment, fire safety and other departments. After the reform and opening up, it is widely used in life and production due to its characteristics of complete sealing, no leakage, and corrosion resistance.

Testing Requirements:
Weekly Run Tests: Diesel pumps should be tested for 30 minutes weekly, and electric pumps should run for 10 minutes.
Annual Flow Tests: Measure pump performance at 100%, 150%, and churn conditions to verify proper operation.
Check Suction & Discharge Pressure: Ensure the pump meets its rated pressure at all test points.
Evaluate System Response Time: Confirm that the pump starts automatically when required.

answer:
1. The raceways of the inner and outer rings are peeled off, cracked or severely worn.
2. The rolling body is out of round or the surface is peeled off, with cracks.
3. The cage is seriously deformed or worn, and the rolling elements cannot be fixed.
4. There is vibration or noise when turning, and there is reverse reversal or braking when stopping.
5. The fit clearance of the bearing exceeds the maximum value of the specified clearance.

The motor fire pump unit is powered by an electric motor to drive the fire pump and output pressure water for fire fighting. The pump unit is mainly composed of a motor, a water pump, a transmission device, a common base and an instrument table. The starter cabinet is installed near the pump unit for starting the motor.
The electric fire pump set has the advantages of quick start, reliable water diversion, stable operation, high degree of automation, wide range of pressure and flow, etc. It is an advanced and reliable fixed fire-fighting equipment.

Challenges in Marine & Offshore Environments:
Corrosion from saltwater exposure.
Harsh weather conditions and high humidity.
Limited space for installation.
Recommended Fire Pump Solutions:
Corrosion-Resistant Pumps: Use bronze or stainless steel materials.
Vertical Turbine Pumps: Ideal for drawing water from the sea.
Explosion-Proof Controllers: Required for hazardous environments.
Remote Monitoring Systems: Essential for offshore platforms.
Compliance:
Must meet NFPA 20, ABS, Lloyd’s Register, and IMO standards.

The high-flow, dual-power fire pump system utilizes a dual-drive configuration—combining diesel and electric power—and offers advantages such as high-volume water supply, automatic control, intelligent monitoring, multiple protection mechanisms, and continuous operation. Suitable for large-scale buildings, industrial facilities, commercial complexes, airports, ports, and municipal fire protection projects, it provides a safe and reliable emergency water supply solution for fire protection systems.
