Skid-Mounted Electric Fire Pump Set – Integrated Configuration for Improved Fire Water Supply Efficiency

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

Prior to installation, fire sprinkler systems are hydraulically calculated to ensure adequate water flow and that the system can reliably suppress a fire until fire crews arrive. When it is determined that there is insufficient flow from a municipal supply for the system to function properly, a fire pump is installed. The fire pump activates when the sprinkler system pressure falls below a certain threshold as a result of sprinkler head operation. To maintain the required operating pressure of the sprinkler system, the fire pump draws additional water from the municipal water supply or on-site storage tanks. Due to the size of piping systems and pressure loss, fire pumps are frequently required in high rise construction and large area buildings.

High-pressure steady-flow fire pump systems offer advantages such as efficient water supply, stable pressure, and intelligent control, ensuring rapid startup and continuous water supply during fire emergencies. The equipment utilizes pressure-resistant and corrosion-resistant materials, variable frequency energy-saving technology, and a fully automatic control system, making it suitable for high-rise buildings, industrial facilities, power stations, and other locations, providing a safe and reliable high-pressure water source for fire protection systems.

The electrical control equipment for fire pumps integrates start-stop control, automatic operation, status monitoring, and electrical protection functions. It can be used in conjunction with electric fire pump sets and achieves linkage control through pressure signals. It is suitable for various building and industrial fire water supply systems.

The fire pump is naturally used in the fire water system, and the technology and raw materials used are all required on site. There are many types of fire pumps and different performances. There may be overlapping performance ranges or large differences in performance. We need to consider the specific functions of the site, such as electric motor fire pumps or diesel engine fire pumps, vertical long-axis fire pumps or horizontal split double pumps. Suction fire pump, horizontal single-stage fire pump, etc., we should choose according to actual needs.

If the person on duty in the fire control room cannot start and stop the fire pump manually after the fire occurs, it will delay the timing of emergency rescue and fire extinguishing. Today ZJBetter is here to explain how to switch the working status of the electrical control cabinet of the fire pump, manually start and stop the pump group on site and remotely, so that everyone can use the fire pump to extinguish the initial fire source or slow down the fire before the fire rescue comes.

Fire pumps work by drawing water from a water source (such as a dedicated water tank or municipal supply) and pressurizing it before delivering it to the fire sprinkler system or hose lines.

Fire pumps are an important part of the fire protection system, especially in high rise structures.In basic 400 – 500 or advanced water situations, fire pumps are important to distribute water into water lines and sprinkler systems where the water pressure of the fire fighting equipment cannot reach. Especially in low-rise structures, fire pumps are important for fire control.
Stylistically, fire protection is a dangerous activity, but without a well-designed and professionally installed system and pump, it certainly becomes more dangerous and commercial assets and lives are less at risk.

Discover the ZJ-Better 304 stainless steel submersible sewage pump — engineered for superior corrosion resistance, reliable drainage, and long-lasting performance in harsh industrial and wastewater environments.

The heavy-duty base fire pump unit features a high-strength structural design and a diesel-driven system, providing a stable and reliable industrial fire water supply solution. Suitable for petrochemical, power generation, and large-scale construction projects, it supports automated control and efficient operation.

Public transportation systems, including subway stations and railway terminals, are complex environments with high volumes of passengers and potential fire hazards from electrical equipment, flammable materials, and mechanical systems. Fire pumps are vital in these settings for delivering the water or suppression agents necessary to extinguish fires in tunnels, platforms, and adjacent facilities. Jockey pumps ensure constant pressure in the system, so fire suppression mechanisms like sprinklers, hydrants, and standpipes are always prepared to respond. Given the confined and underground nature of many transportation hubs, fire protection systems must be capable of addressing fires in tight, poorly ventilated spaces while facilitating the safe evacuation of passengers. The pumps also need to support fire hose connections for firefighters, who might need to cover long distances within tunnels or elevated railways. Regular inspections and emergency drills are essential to ensure that fire pumps are fully operational and integrated with ventilation and evacuation systems, providing a coordinated response to fire emergencies in these high-risk, densely populated environments.

EDJ fire pump has the characteristics of high efficiency, wide performance range, safe and stable operation, low noise, long life, convenient installation and maintenance. For conveying clean water or other liquids similar to water in physical and chemical properties.

Dual power emergency fire pump system combining electric and diesel driven pumps to ensure uninterrupted fire water supply during power outages and extreme conditions. Featuring automatic control, pressure stabilization, high efficiency performance and reliable operation, ideal for industrial, commercial and municipal fire protection applications.

The diesel engine fire pump is usually used as a backup facility. It will only start automatically when the electric water pump fails or is powered off when the fire signal comes. When equipped with an ultra-low pressure pump starting device, the matching electric pump control cabinet should also be equipped with an ultra-low pressure pump starting device, and the lower limit of the pump should have a certain pressure difference. Of course, it is also possible to design a control system that is more suitable for customer needs according to customer requirements.

1.Flow: 50-5000GPM
2.Head: 3-20Bar
3.Speed: 740-2900r/min
4.Power: Electric pump: 1.5-710 kw, Jockey pump: 0.55-160kw
5.Caliber: 25-800mm
6.Material: HT200，SS304，Bronze
The EEJ Fire Pump System includes two electric pumps and a jockey pump.

Stabilized support trailer mounted fire pump designed for enhanced on-site safety and reliable high-pressure water supply. Featuring independent diesel power, heavy-duty chassis, multi-point support legs and long-distance mobility, ideal for mining, oil & gas, industrial plants and municipal emergency fire protection applications.

The EJ Dual Power Fire Pump System is an innovative and reliable fire protection solution. Combining an electric pump for robust water pressure and flow with a top-quality jockey pump for stable pressure maintenance, this system ensures efficient and timely water supply during fires. With advanced automation, remote monitoring, and energy-saving features, the EJ Dual Power Fire Pump System is a trusted choice for commercial, industrial, and residential applications.

Discover the advantages of an electric-driven integrated fire pump system, offering high efficiency, stable pressure, intelligent control, and space-saving design for reliable fire protection in commercial, industrial, and high-rise buildings.

Powerful diesel fire pump unit designed for continuous heavy-duty operation, delivering high head and large flow for reliable firefighting performance. Features stable output, efficient cooling system, low maintenance design, and intelligent control, ideal for industrial facilities, warehouses, energy projects, and critical fire protection applications.

The diesel engine fire pump is usually used as a backup facility, so it will only start automatically when the fire signal comes, and when the electric water pump fails or the power supply is cut off. When it has an ultra-low pressure start-up device, the matching electric water pump control cabinet should also have an ultra-low-pressure start-up device, and the lower limit of the two pumps should have a certain pressure difference. Of course, according to customer requirements, design a control system that is more suitable for customer needs.

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

High-temperature resistant fire-fighting water supply equipment has the advantages of stable operation in high-temperature environments, high-efficiency water delivery, intelligent control and continuous water supply, and is widely used in petrochemical, power energy and industrial fire protection projects.

Fire pump package comprises a combination of electric motor driven pump, diesel engine driven pump and electric motor driven jockey pumps that supply for fire suppression systems.

Fire pumps are part of the water supply to a fire sprinkler system and are powered by electricity, diesel or steam. The pump inlet is either connected to a public groundwater supply or to a static water source (e.g. tank, reservoir, lake). This pump provides higher pressure water flow to sprinkler system risers and hose risers.

This innovatively designed fire pump system is specifically tailored for environments with high firefighting water supply requirements, such as industrial parks and high-rise buildings. By incorporating high-efficiency pumps and intelligent control technology, the system ensures the rapid provision of high-volume water during a fire, meeting the demands of complex environments. The system integrates both diesel and electric drive motors, combined with an intelligent control panel that offers automatic start-up, water pressure regulation, remote monitoring, and fault alarms, ensuring stability and efficiency during critical moments.

The innovation in this product is also reflected in its modular design, allowing for flexible configuration based on different application scenarios. The system is easy to install and commission, making it adaptable to various complex operational environments. Additionally, its high durability and low maintenance costs ensure that it continues to perform excellently over time, making it the ideal choice for ensuring fire safety in industrial parks and high-rise buildings.

Skid mounted diesel driven fire pump designed for temporary and permanent fire protection systems, delivering high flow, stable pressure and reliable independent operation. Ideal for industrial plants, warehouses, construction projects and municipal facilities, featuring modular structure, easy installation and long-term continuous performance.

Jockey pumps are a vital component in maintaining the pressure within a fire protection system. Their primary role is to keep the system’s pressure within the desired range. When there’s no fire event, the jockey pump operates to counteract any pressure losses due to minor leaks or gradual pressure decreases in the system.

By maintaining system pressure, jockey pumps ensure that the primary fire pump is ready to respond quickly and efficiently when a fire occurs. This pressure stability is crucial for the proper functioning of the entire fire protection system, allowing for immediate water flow to sprinklers or hose connections.

Discover the intelligent management and maintenance advantages of electric-driven fire pumps. Learn how these advanced systems enhance performance, reliability, and energy efficiency for modern fire protection solutions.

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

Diesel engine fire pumps are widely used in firefighting equipment due to their various advantages. Most firefighting equipment will choose to use this equipment, which has various automation functions and can be connected with other equipment according to customer needs. It is a kind of equipment with good starting characteristics, strong overload capacity, compact structure, convenient maintenance, simple use, and a high degree of automation.
