30 HP EJ fire pump package dispatch to Manila

An anechoic check valve, control valve and pressure gauge should be installed on the discharge pipe of the fire pump; a pressure gauge and pressure switch should also be installed on the total discharge pipe of the system; a buffer device should be added when installing the pressure gauge. A cork should be installed between the pressure gauge and the buffer device; the pressure gauge range should be 2 times to 2.5 times the working pressure of the system when there is no design requirement.

Diesel pumps can be combined with electric pumps, jockey pumps, etc. to form an automatic water fire-fighting water supply system, and can be linked with the fire control center.

When the pump set receives the starting command, if the mains power is cut off, the automatic control cabinet of the diesel engine will immediately send a start signal to the starting motor of the pump set to start the motor to start the diesel engine at idle speed, and then gradually adjust the throttle to accelerate the diesel engine to the rated speed . The control system will automatically monitor the operation of the diesel engine, such as the oil pressure, oil temperature, speed of the diesel engine, outlet pressure of the water pump, etc., and determine whether the diesel engine starts normally through automatic monitoring. If the start fails, the control system will send a restart signal, and if the three starts fail, the automatic control system will send a failure alarm. When the pump set receives a signal that the pressure of the pipeline network is restored or the mains power is restored to normal, the pump set will quickly slow down and stop automatically after monitoring the idle position for a period of time.

The full name of diesel engine fire pump is engineering diesel engine fire pump set, which can be automatically charged, automatically started, and has the functions of automatic alarm and automatic preheating. The diesel engine fire pump is usually used as a backup facility, so it will only start automatically when the fire signal comes, and when the electric water pump fails or the power supply is cut off. When it has a device for starting the pump at ultra-low pressure, its matching electric water pump control cabinet should also have a device for starting the pump at ultra-low pressure, and the lower limit of the two pumps should have a certain pressure difference.

1. Electric fire pump: various end suction pumps and split pumps.
2. jockey pump: vertical, small flow, higher lift than electric or diesel pumps.
3. Control panel: Automatically control the water pump with overload and overcurrent protection.
4. Accessories: suction pipe, discharge pipe with flange, battery, gate valve, check valve, flexible expansion joint, pressure switch, pressure gauge, base, etc

Get to know the fire pump room layout standards per NFPA 20, including access, spacing, and equipment clearance.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

If the fire pump is corroded, it should be inspected by a qualified professional. Depending on the extent of the corrosion, the pump may need to be repaired or replaced. The professional may also need to inspect the entire system for any other potential issues. In some cases, a fire pump may need to be replaced if the corrosion is severe and cannot be repaired.

EDJ fire pump set is composed of electric pump + diesel pump + jockey pump. The pump set has reasonable layout, firm installation, reliable connection, compact and neat structure, and convenient maintenance. And can run in the case of power failure, suitable for any emergency fire occasions.

There are numerous ways to maintain fire pumps and water pumps. The following styles are more effective. You can use them for reference
System 1 The installation of the pump set should be accurate and dependable, and there should be no egregious vibration duringoperation.However, or the bearing is hot to the touch( the temperature is advanced than 60 °C) and the water seepage in the seal of the pump shaft is further than 60 drops per nanosecond, the cause must be set up out and the fault should be excluded in time, If the pump makes abnormal noise when pumping water.
the
system 2 Screws that are squinched daily, similar as packing gland screws, irrigation entrapments,etc., should be disassembled with a suitable wrench and a reasonable necklace. You can put some slicking oil painting on it or wipe it regularly with an oil painting cloth to help rust; if the water drain screw isn’t used constantly, it’s easy to rust, so after buying a new water pump, you should first wind the water drain draw, and apply some machine oil painting and white lead oil painting on the screw thread, Change the new oil painting two or three times a time in the future.
the
System 3 If the pump is waxed with machine oil painting, the slicking oil painting should be replaced once a month; if it’s waxed with adulation, it should be replaced every six months. It should be noted that the water pump uses calcium- grounded grease, and the motor uses sodium- grounded grease, and they shouldn’t be used inaptly. Because sodium- grounded grease is hydrophilic, it’ll emulsify into froth and dissipate when it encounters water on the pump, while calcium- grounded grease is hysterical of high temperature, so it’s easy to melt when the temperature rises when used on a motor.

system 4 Don’t pump water with too important beach, so as to avoid unseasonable wear and tear of the impeller, mouth ring and shaft, and try to help water deficit operation. Running without water will damage the water seal, and the water pump is prone to water leakage or indeed no water.
System 5 After the irrigation and drainage season is over, the water pump should be precisely gutted and auditedimmediately.However, they should be repaired or replaced in time, and the corridor that should be waxed should be filled with suitable oil painting; Stylish stored in a dry place, If any damaged or misshaped corridor are set up to be unworkable.

Multi stage pump refers to a pump with two or more impellers, which can absorb and press water in stages and stages, so as to lift the water to a very high position. The lift can increase or decrease the number of stages of pump impellers according to needs; When the single-stage pump head needs to be equipped with two-stage motors, the multi-stage pump can be equipped with four-stage motors by increasing the number of impellers, which can improve the service life of the pump and reduce the noise of the unit. When the actual required lift of the pump is less than 125 meters, the selection of a single-stage pump or a multi-stage pump can be comprehensively considered according to the area of the pump room, the pump price (the price of a multi-stage pump is generally higher than that of a single-stage pump) and other factors.

The EDJ （Diesel Pump:IS, Electric Pump:ISW）Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

No, a fire pump should never run without water. Running a fire pump dry can cause significant damage to the pump’s internal components, leading to overheating and failure. Ensuring the water supply is reliable and monitored is essential for proper fire pump operation.

The electric fire pump unit is mainly used for fire hydrant fire extinguishing, automatic sprinkler fire extinguishing and other fire extinguishing systems of industrial and mining enterprises, engineering construction, high-rise buildings and other fixed fire extinguishing systems. It can be used to transport clear water without solid particles and media similar to water in chemical properties. It can also be used in common water supply systems for living and production, as well as construction, municipal water supply and drainage, etc.

The basis for the selection of fire pumps should be based on the process flow, water supply and drainage requirements, and be considered from five aspects, namely, liquid delivery volume, device lift, liquid properties, pipeline layout, and operating conditions. Fire pumps are mainly divided into vertical and horizontal types. The flow rate of the conveying liquid is one of the important performance data for pump selection. It is directly related to the production capacity of the entire device. The working conditions of the fire pump: flow rate: 2～1400m3/h, Head: 5～130m, maximum working pressure of the system: ≤1.6MPa, working temperature: -15℃～+80℃.

This equipment is an EEJ fire pump set customized by a Greek customer with a frequency of 50Hz. The electric pump adopts an XA pump.This pump combines the advantages of similar products in China and abroad, and is designed with excellent hydraulic model.Therefore, its excellent hydraulic performance and structural characteristics ensure that users can effectively reduce the operation cost of pumps in various applications.

EEDJ Fire Pump Package ,The equipment is designed to have 2 electric pumps. one duty and one standby and one diesel pump stand by function. The main pump runs normally, and the standby pump starts automatically after the main pump fault . The Jockey pump will start and stop based on the pipe pressure, Control panel site start.

Fire pumps are subject to rigorous testing and maintenance protocols to ensure they are always ready to operate in an emergency. This typically includes regular weekly or monthly churn tests, where the pump runs without discharging water, and annual flow tests, which verify that the pump can achieve its rated flow and pressure. These tests are crucial for identifying potential issues, such as wear and tear on components, blockages in the piping, or problems with the power supply. Additionally, fire pumps must be inspected for leaks, corrosion, and other signs of deterioration. Regular maintenance, including lubrication, alignment checks, and part replacements, helps extend the pump’s lifespan and ensures its reliability when needed most.

Fire pumps are critical components of fire protection systems, and their reliable operation is essential for effective fire suppression. However, like any mechanical equipment, fire pumps can experience various issues over time. Some common problems associated with fire pumps include:

Flow: 30-500GPM
Head: 3-20Bar
The ED Dual-Power Fire Pump System combines electric and diesel engine pumps to ensure uninterrupted fire protection and a reliable water supply. In the event of power outages or electrical failures, the diesel engine pump seamlessly takes over, guaranteeing continuous operation of the fire protection system. This dual-power configuration offers both reliability and flexibility, providing comprehensive coverage for fire safety needs.

When we buy fire pumps, we all encounter this situation: the products we buy fail to meet the parameters required by ourselves, or exceed the parameter range required by ourselves, resulting in that they cannot be used. Or the product is not the type you want, which shows the importance of product testing.

1.Flow：30-9000 GPM
2.Head： 3-20 Bar
The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations.

Diesel engine fire pump has the advantages of light weight, small size, flexible movement, fast start, fast water discharge time, large fuel tank capacity, corrosion resistance, reliable use, convenient maintenance, fast automatic start, self-starting, and can be refueled after dry operation . Heavy-duty pump bearings last longer; other components are made of high-quality copper and stainless steel or customer. Diesel engine fire pump high efficiency open impeller design can handle large solids and abrasives while maintaining high flow rates and high volume air handling for use in more “well point dewatering projects”.

The equipment is designed to have one duty and one standby function. The main electric pump runs normally, and the standby diesel pump starts automatically after the main pump fault . The Jocky pump will start and stop based on the pipe pressure, Control panel site start.

When facing the fire risks in modern buildings and industrial facilities, firefighting efficiency and reliability are the foremost considerations. Electric fire pumps are the ideal solution for tackling fire challenges in complex environments, offering high efficiency, stability, and smart control systems. Whether in high-rise buildings, industrial parks, chemical plants, or power facilities, electric fire pumps ensure exceptional performance.

Firstly, electric fire pumps are equipped with high-performance electric motors, ensuring the stable operation of the pump through intelligent control systems. In the event of a fire, the system responds quickly and activates the pump, providing a steady water flow to extinguish the fire. Especially in complex environments such as narrow spaces, high-temperature settings, or areas requiring highly precise control, the electric fire pump continues to operate efficiently, ensuring the successful execution of firefighting tasks.

Moreover, the smart control system of the electric fire pump continuously monitors the pump’s operational status, conducts self-diagnostics, and adjusts pressure and flow, ensuring no performance degradation during firefighting operations. Its compact design allows it to fit into spaces with limited room while maintaining top-notch performance.

With the increasing emphasis on environmental protection and energy efficiency, the low energy consumption and high performance of electric fire pumps make them increasingly popular in the market, playing a critical role in optimizing firefighting efficiency.

As a fixed firefighting equipment, diesel engine fire pumps are widely used in firefighting and shunting operations, especially when there is no power supply or no power supply (main power supply).
Diesel fire pumps can also be equipped with other diesel engines as power engines according to user needs. It is mainly composed of diesel engine, fire pump, connection device, fuel tank, radiator, battery, intelligent self-control panel, etc. The crankshaft of diesel engine fire pump has high overall rigidity, high strength and high torque transmission efficiency. Adopt international advanced technology, sliding bearing, plate-fin cooler, upper heat exchanger, rotary oil filter, double cooling system. Diesel engine fire pump performance, smoke and noise indicators meet national standards.

Flow: 30-9000 GPM
Head: 3-20Bar
Speed: 740-2900r/min
Material: HT200, SS304, Bronze
The EJ Dual Power Fire Pump System is an innovative and reliable fire protection solution. Combining an electric pump for robust water pressure and flow with a top-quality jockey pump for stable pressure maintenance, this system ensures efficient and timely water supply during fires. With advanced automation, remote monitoring, and energy-saving features, the EJ Dual Power Fire Pump System is a trusted choice for commercial, industrial, and residential applications.

EDJ fire pump set is composed of electric pump + diesel engine pump + jockey pump. The fire pump set has the characteristics of high efficiency and energy saving, reliable quality, strong overload capacity, compact structure, convenient maintenance and high degree of automation. Suitable for any emergency firefighting occasion.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

Philippines clients DJ fire pump set waiting for package and dispacth
250gpm 8bar DJ fire pump, with ISW model engine pump and one jockey pump on one skid
