Highly Reliable Fire Pump Set to Meet Firefighting Challenges in Complex Conditions

The dual pump system is an important innovation in fire pump design, offering more efficient and stable fire protection. By incorporating two pumps, the system ensures that if one pump fails, the other can continue to provide steady water flow and pressure, ensuring the reliability and stability of the fire protection system during emergencies.

Compared to single pump systems, dual pump systems not only provide redundancy but also enhance the system’s flexibility. The system can automatically switch between pumps based on firefighting requirements, ensuring optimal water flow and pressure for fires of varying scales. Whether in high-rise buildings, industrial parks, or large commercial facilities, dual pump systems can effectively handle complex fire protection needs.

Additionally, the dual pump system incorporates smart control technology, enabling automatic start-stop, remote monitoring, and fault warnings, greatly enhancing operational convenience and safety. The modular design of the fire pumps simplifies system maintenance and repairs, reducing the likelihood of equipment failure and extending service life.

With an efficient dual pump system, you can significantly improve the reliability of your fire protection system, ensuring a powerful and stable firefighting capacity when it matters most.

·UL Standard
Flow：50-3000 GPM
Head： 5-20 Bar (72.5-290 psi)
Speed：740-2900 r/min
·Non-UL Standard
Flow：30-9000 GPM
Head： 3-20 Bar (40-300 psi)
Speed：740-2900 r/min

Diesel engine fire pumps are suitable for use in high lift and high flow fire water supply environments or as backup fire water supply pumps. The reason is that the diesel engine has strong power and can be used with large flow fire deep well pumps, and the diesel engine fire pumps have the characteristics of self-starting when power is off. Emergency water supply is available, so a diesel engine fire pump is a good choice.

UL fire pump, certificate number EX28132,
meet UL 448 standard for pumps for Fire-Protection Service
Flow 200-2000 GPM
Rated pressure: 103-224 PSI
Speed： 2950-3550 RPM (50hz or 60hz)
Maximum working pressure: 280 PSI

The EJ model is basically a combination of an electric drive and a jockey pump. They consist primarily of an end suction pump driven by an electric motor, with no backup pump. It is also combined with a jockey pump for maintenance to form a complete skid.

The complete EJ-style skid is assembled with all discharge line accessories and connected to the skid-mounted control panel.

Self-priming fire pumps offer fast startup, no foot valve, and easy maintenance—ideal for industrial sites, emergency zones, and temporary fire systems.

Jockey pumps help extend the lifespan of fire pumps by maintaining system pressure and preventing unnecessary cycling of the main fire pump. By handling minor pressure fluctuations and small leaks, jockey pumps reduce the wear and tear on fire pumps, which would otherwise start and stop frequently to maintain pressure. This reduced cycling minimizes mechanical stress on the fire pump’s components, such as bearings, seals, and impellers, thereby prolonging its operational life. Additionally, jockey pumps consume less power and operate more quietly than fire pumps, leading to energy savings and reduced noise pollution in facilities. By ensuring that fire pumps only operate during actual emergencies, jockey pumps contribute to the long-term reliability and efficiency of the fire protection system.

The EJ Dual Power Fire Pump System is an innovative and reliable fire protection solution. Combining an electric pump for robust water pressure and flow with a top-quality jockey pump for stable pressure maintenance, this system ensures efficient and timely water supply during fires. With advanced automation, remote monitoring, and energy-saving features, the EJ Dual Power Fire Pump System is a trusted choice for commercial, industrial, and residential applications.

Fire Hydrant and Fire Sprinkler System 38lps, 60m
Fire Fighting Pump Set
Fire Fighting Pump with Electric Motor, diesel engine and jockey pump , 200L pressure vessel

Fire pumps are designed to start promptly in case of an emergency. The time it takes to start depends on factors such as the type of pump (electric or diesel) and the specific system design. Regular testing helps ensure quick response times.

High-performance diesel fire pump system integrating a powerful diesel engine, centrifugal pump, and intelligent control panel. Designed for automatic operation and emergency fire protection during power outages. Ideal for industrial plants, oil storage facilities, ports, airports, and high-rise buildings. Features include high flow rate, fuel efficiency, corrosion resistance, and customizable design. Certified to ISO, CE standards, making it suitable for international markets in the Middle East, Southeast Asia, and Africa.

The lower the pumping head of the fire pump, the smaller the motor load. Under the misleading of this kind of misunderstanding, when purchasing a water pump, the head of the water pump is often selected to be very high. In fact, for centrifugal water pumps, when the pump model is determined, the power consumption is proportional to the actual flow of the pump. The flow rate of the water pump will decrease with the increase of the head, so the higher the head, the smaller the flow rate and the smaller the power consumption. Conversely, the lower the lift, the greater the flow and the greater the power consumption. Therefore, in order to prevent the motor from overloading, it is generally required that the actual pumping head of the pump should not be lower than 60% of the calibrated head.

Flow: 5-120L/s

Head:0.2-1.6MPa

Caliber: 50-250mm

Power: 3-220kW

Speed: 1500-2600r/min

Working Pressure: 1.6MPa

EDJ fire fighting equipment consists of electric pump + diesel pump + jockey pump. Both the electric pump and the diesel pump use a multistage jockey pump with large flow and high lift. The diesel engine can be started without electricity. It is suitable for any fire protection occasion. The company has a professional sales and production team, and the choice of pumps can be customized according to their own needs.

EDJ fire pump set consists of main electric pump (motor driven), standby diesel pump (diesel engine driven) and jockey pump. The pump is assembled from discharge and suction pipes and a control panel. The fire pump system can be customized for different uses such as high-rise buildings, warehouses, facilities, hospitals, supermarkets, shopping malls, villas, apartments, etc.

Learn how to prevent fire pump cavitation with proper suction design, pump sizing, and maintenance tips to protect your system and ensure reliable performance.

In industrial settings, fire pump systems play a crucial role. Efficient and stable fire pump equipment can start quickly during emergencies, providing strong water pressure and flow to ensure effective fire suppression. Our meticulously designed diesel fire pump system features durability and reliability, operating steadily even in harsh environments. The intelligent control panel monitors the equipment status in real-time, ensuring optimal performance. Widely used in chemical plants, power stations, and warehousing logistics, it safeguards fire safety for industrial enterprises.

EEDJ fire pump testing 250gpm, 6bar now!all product before shipment, we will do tesrting, then send to customers

The minimum rated fire pressure of dual power is 0.3MPa, and the minimum rated fire
rated work flow is 2L/S. Dual power includes motor pumps, engine pumps, pressure
stabilization pumps, diaphragm pneumatic tanks, pipes, valves, electrical control systems,
control sensors and other related accessories driven by at least two power sources. Fire
water supply equipment is continuously supplied to the fire control network by preset mode.
The arrangement is reasonable, the installation is firm, the connection is reliable, the
structure is compact and neat, and is convenient for maintenance and overhaul

The EDJ Diesel Engine Fire Pump System is a powerful and reliable firefighting equipment designed for fire suppression and emergency rescue operations. It boasts high-performance capabilities in water extraction and pressure delivery, enabling rapid supply of large volumes of water. The system operates independently, ensuring its reliability even in challenging situations. With its lightweight and portable design, coupled with versatile functionality, the EDJ Diesel Engine Fire Pump System is suitable for various scenarios. Whether you are part of a fire department or an industrial enterprise, the EDJ Diesel Engine Fire Pump System is your indispensable rescue partner.

Diesel integrated fire pump system for harsh environments, offering stable pressure, fast startup, and modular installation for emergency use.

1.Flow: 50-5000GPM
2.Head: 3-20Bar
3.Speed: 740-2900r/min
4.Power: Electric pump: 1.5-710 kw, Jockey pump: 0.55-160kw
The EEJ Fire Pump System includes two electric pumps and a jockey pump.With exceptional performance and efficiency, the EEJ Fire Pump System delivers high pressure and large flow capacity, enabling rapid and effective fire suppression.

1. Electric fire pump: various end suction pumps and split pumps.
2. jockey pump: vertical, small flow, higher lift than electric or diesel pumps.
3. Control panel: Automatically control the water pump with overload and overcurrent protection.
4. Accessories: suction pipe, discharge pipe with flange, battery, gate valve, check valve, flexible expansion joint, pressure switch, pressure gauge, base, etc

Now the general diesel engine fire pump set is powered by imported or domestic Cummins, Wuxi Power Engine Factory and other diesel engines produced by large-scale key enterprises in the internal combustion engine industry at home and abroad, through highly elastic couplings or diaphragm couplings produced by professional manufacturers. The engine is directly connected with the water pump, and the power of the diesel engine can reach 880KW. It can be equipped with water pumps of different lifts and flow rates for customers to choose and use according to different needs.

Yes, various national and local codes and standards, such as NFPA 20 (Standard for the Installation of Stationary Pumps for Fire Protection), provide guidelines for the installation, operation, and maintenance of fire pumps.

The EJ Dual Power Fire Pump System is an innovative and reliable fire protection solution. Combining an electric pump for robust water pressure and flow with a top-quality jockey pump for stable pressure maintenance, this system ensures efficient and timely water supply during fires. With advanced automation, remote monitoring, and energy-saving features, the EJ Dual Power Fire Pump System is a trusted choice for commercial, industrial, and residential applications.

Firefighting pumps can be powered by various sources, including gasoline engines, diesel engines, electric motors, and even manual operation in some cases. The choice of power source depends on factors such as portability, availability of fuel, and the intended application.

The minimum fire rated pressure of ED small fire fighting package set water supply equipment is 3 bar and the minimum fire rated capacity is 25 GPM. ED small fire fighting package set water supply equipment includes at least two power or power source driven pumping units, pressure tanks, pipes, valves and accessories, measurement and control instruments, control cabinets, outdoor rain cover, etc.
Motor: Three-phase asynchronous squirrel-cage motor independently developed and manufactured by our company, which can be controlled in production time and greatly shorten the whole set production time.
Diesel Engine: According to the different parameters of customers, we will choose diesel engines with high cost performance ratio. The main brands are QuanChai, Weichai, ShangChai, FAWDE, Cummins, etc.
Electric Pumps: Electric pumps can use vertical in-line pumps, horizontal end-suction pumps, vertical multi-
stage pumps, horizontal multi-stage pumps, split casing pumps and so on according to the different flow and head of customers.
Diesel Pumps: Diesel pumps can use vertical in-line pumps, horizontal end-suction pumps, vertical multi-
stage pumps, horizontal multi-stage pumps, split casing pumps and so on according to the different flow and head of customers.
Electronic Components: The main electric components is CHNT, if Schneider or other brand electrical are need, should mention it before place the order.
Safety Valve plays a safety protection role in the system. When the system pressure exceeds the prescribed value, the safety valve opens, and a part of the gas/fluid in the system is discharged into the atmosphere/pipeline, so that the system pressure does not exceed the allowable value, so as to ensure that the system does not cause accidents due to excessive pressure.
Pressure Tank: Water is a non-compressible medium. Generally speaking, the pressure drop of fire-fighting pipe network is normal. However, the pressure drop is very slow, the total loss of water in the pipe network isnot large, and the frequent change of pressure in the pipe network leads to frequent start-up and shutdown of pumps. Especially when the power of equipment is high, it will cause great impact on pressure sensors, relaysand motors, thus affecting the performance and life whole equipment. Therefore, it is necessary to choose the right volume of the pressure tank.

DJ fire pump set consist of diesel pump, jockey pump and control panel. The diesel engine is fixed on the base with anti-vibration rubber pads and the pump is directly coupled to a diesel engine through flexible coupling, According to the power output of the engine the electrical system, the diesel engine can be Cummins,Deutz,Perkins and Other China brand engine(Shangchai,Yuchai,ec.) and it consists of alternator, started motor, fuel system, lubricating system, exhaust system, etc.

Diesel engine fire pump set is a new type of fire-fighting equipment developed by our company in strict accordance with the national standard GB6245-98 “Fire Pump Performance Requirements and Test Methods” and the American Fire Protection Association standard NEPA20 “Installation of Centrifugal Fire Pumps” and other standards (hereinafter referred to as equipment ), this series of equipment can be divided into three sub-series, XBC-IS, XBC-SLOW, XBC-D, etc. The equipment has a wide range of pressure and flow, and its application can almost meet various occasions required by fire protection.
